Series N800 Hose Reel

Name: Series N800 Hose Reel - Mansour Group Inc
SKU: HD-3.17.028
Price: 0.01 CAD
Availability: InStock

SKU/part: #HD-3.17.028

To handle 3/4″ or 1″ I.D. hose. Most Hannay spring reel models are available with an air governor rewind assist, which prevents the hose from winding back onto the reel too quickly. Speed is regulated by restricting air flow through an air governor attached to the rewind mechanism. The result is smooth, controlled rewind speed each and every time. Choose from 4 different roller positions. SR and VR roller positions: swivel joint is standard on the right. TR roller positions: swivel joint is standard on the left. Other configurations available on request.

Hose Size & Capacity

Inventory Disclaimer:
Please note that product availability is subject to change and may vary from what is listed online. We recommend calling ahead to confirm stock before visiting our location in person. When you request a quote, a sales representative will confirm current availability and provide updated details.

Product Features
Narrow frame and compact mounting base.
Non-sparking ratchet assembly.
Declutching arbor to prevent damage from reverse winding.
Standard inlet: 90 degree balanced pressure swivel joint, 1″ female NPT threads.
Standard outlet: 1″ female NPT threads.
Standard pressures to 2000 psi (138 bar), available up to 6000 psi (414 bar) must specify.
Standard fluid temperatures from -40 F to 250 F (-40 C to +121 C).
Constant tension is available, consult factory.

General Applications

The Hannay Reels N800 Series is used across many industries, including agriculture, construction, industrial, transportation, utilities, fire and rescue, fuel dispensing, and waste management, for applications like fuel dispensing, waste oil evacuation, air/water supply, and chemical transfer. The N800 Series is versatile, handling hoses up to 1-inch internal diameter for general industrial and specialized applications.
